Santa Fe Advance Dehumidifier

therma-stor santafe
duct kit attached     with pump   ...
View Larger Image

This compact and powerful dehumidifier (model # 4025699) was designed for use within crawl spaces up to 2200 square feet in size. It is the perfect solution for moisture problems in crawl spaces and can also be used within medium-sized basements. It is able to remove over 90 pints of water per day at AHAM, 180 pints at saturation, and can operate down to 55º F.
Free Digital Humidity Gauge with Purchase.

In Stock - Usually ships in 24 hours

Free Shipping

Item#: sa506

Price: $1085.00



Email A Friend
Print Page
Call 24 Hours
Free Shipping
30 Day Money Back
Better Business Bureau Online
HACKER SAFE certified sites prevent over 99.9% of hacker crime.
User Rating: (2 customer reviews) - Write a Product Review
Overview & Highlights

Accessories:

View All Related Accessories
Santa Fe Advance Standard Filter (4025568)
Advance Standard Filter (4025568)

Item# sa663
$34.00

Santa Fe Advance Pump Kit (4025845)
Optional Advance Pump Kit (4025845)

Item# sa662
$119.99

Santa Fe Advance Pre-filter (4025831)
Advance Pre-filter (4025831)

Item# sa664
$34.00

Santa Fe Advance Duct Collar Kit (4026055)
Optional Advance Duct Collar Kit (4026055)

Item# sa661
$99.99

no image available - Register Head
8 Inch Register Head (4027430)

Item# sa1076
$34.99
View All Related Accessories



We also recommend:
therma-stor crawlspace
Santa Fe HC Crawl Space Dehumidifier

Item# sa438
$1685.00

therma-stor santafe
Santa Fe Classic Dehumidifier

Item# sa154
$1285.00

This American-made horizontally designed unit (model # 4025699) shares the same efficiency and reliability as the upright stand-alone Santa Fe units. The only real difference lies in its unique design, which allows the unit to be conveniently placed inside height-restricted spaces.

Under ideal conditions the Santa Fe Advance can cover as much as 2200 square feet, eliminating over 90 pints per day at AHAM and 180 pints at saturation. However, when it comes to large spaces, it's best to get a consultation on your specific environment. Please call our product experts at (800) 934-9194 for a free profile and recommendation.

Also, see our Frequently Asked Questions about the Santa Fe Advance for more information.

Product Profile
This high-capacity dehumidifier is highly reliable and comes with everything you need to start eliminating excess moisture from the air:

  • Unit
  • Prefilter
  • Pleated secondary filter
  • 4 Removable Legs
  • 10 ft Power Cord
  • 8 ft Drain Hose
  • Manual
  • Registration Card
  • Free (by mail) Digital Humidity Gauge Included with Purchase

How It Works
This high-efficiency residential dehumidifier utilizes refrigeration to cool the incoming air stream below its dew point as it passes through the dehumidification (evaporator) coil. This cooling results in the removal of moisture (latent heat) and reduction of the temperature (sensible heat). The cooled and dried air is used to pre-cool the incoming air stream resulting in up to a 200% increase in overall efficiency. After the pre-cooling stage, the processed air is reheated by passing through the condenser coil. The latent heat removed by the evaporator coil is then returned to the air stream as sensible heat, resulting in an overall increase in temperature from the incoming air.

Designed To Fit Your Needs
The unique design of the crawl-space Advance offers you several options, as you have the ability to place it in a finished basement, unfinished basement, or simply on open dirt/earth in a crawl space; with such a small physical profile, you can easily set the unit up wherever you need. If you choose to place the unit on open ground, it is good to put plastic down across the whole surface area, which will provide additional moisture insulation for your space and allow the system to work even more effectively.

The unit comes with four removable legs (a new feature) that can be adjusted to level the machine in the space.

Control Panel

Temperature Operation
This Santa Fe system is designed to run efficiently in temperatures between 55°F and 95°F, which typically include lower temperatures found in basements and crawl spaces.

Humidity
When appropriately sized, this system will maintain the EPA recommended relative humidity of 45% to 50% — ideal conditions for an odor free, dry comfortable living and storage space. This unit is able to eliminate over 90 pints of water per day at AHAM and 180 pints at saturation.

Special Features
This commercial-grade, ultra-efficient system stands far above its competitors when it comes to the amount of water it can absorb from the air at the least cost to you. It comes with a number of specially designed features:

  • A separate fan control allows for continuous fan operation, or operation only when the unit is actively removing moisture from the air.
  • A humidity control knob allows unit to turn on and off automatically to maintain the humidity level that is ideal for your environment.
  • Washable pre-filter.
  • Pleated air filter for finer particle removal.

Santa Fe Advance Open with Filter

Filter
The Santa Fe has a standard filter that helps to reduce the amount of dirt and particles that can get into the machine. This filter should be changed between 6 months and a year, depending on how polluted it becomes.

Ducting
This unit can be used in some situations where ducting the unit is required. Ducting might be needed to increase the circulation of the air by placing one or two ducts to remote areas of the space being dehumidified. However, this unit is not easily connected to a remote humidistat so it is recommended this unit be located in the area being dehumidified.

Condensate Pump Option
If the gravity drain isn’t a possible option for eliminating the collected water, a condensation pump kit is available. This unit is easily adaptable to use a condensate pump, and this will give you the option of running the drain hose up and out a window or around a doorway to your yard or garden. These pumps are energy efficient as well and work with a flow switch that allows the pump only to run when needed.

Energy Star Rated

ENERGY STAR Rated
These units are Energy Star rated, meaning they are an energy efficient choice that is good for your finances and for the environment. Products labeled ENERGY STAR have the special distinction of being high energy-saving appliances that don't sacrifice performance, style, or quality. Choosing an ENERGY STAR product means you get the results you want without creating pollution or consuming excess energy.

Furthermore, the Santa Fe line of units are the most energy efficient units of all Energy Star-rated dehumidifiers as confirmed on our May 2005 specifications chart comparing all Energy Star units. As such, these units will cost less to run per pint of water removed from the air than any other units on the market.

Mini Hydro-Thermometer

This unit comes with a Free Digital Humidity Gauge & Thermometer (by mail in rebate included).



Product Specifications

  • Capacity @ AHAM : 90 pints
  • Capacity @ Saturation : 180 pints
  • Lowest Operating Temperature : 55º F
  • Humidistat : Yes
  • Continuous Drain Capable : Yes
  • Dimensions (H x W x D) : 19" x 14.5" x 33"
  • Controls (Manual / Electronic) : Manual
  • Cubic Feet per Minute (CFM) : 240 CFM
  • Auto-Restart on Power Failure : Yes
  • AMPS : 6.35 AMPS
  • Energy Star Rated : Yes
  • Water Container : No
  • Full Bucket / Auto Shut-Off : No
  • Weight : 71 lbs
Warranty
1 Year on Parts; 5 Years Limited on Sealed System Parts (compressor, evaporator, etc)

What is in the box
Unit
4 Leveling Legs
Prefilter
Pleated Secondary Filter
Drain Hose
Product Literature
Mail-in Certificate for Free Digital Hygrometer

Reference Materials

Sales Sheet (Adobe PDF)
Information highlighting the unit's features

Energy Star Comparison List (Adobe PDF)
Chart comparing energy star units

Spec Sheet (Adobe PDF)
Detailed product specifications

Product Manual (Adobe PDF)
User manual from the manufacturer

Warranty (Adobe PDF)
Manufacturer's warranty information

Ducting Kit (Adobe PDF)
Information on ducting the unit (optional)

Condensate Pump (Adobe PDF)
Information on setting up the optional condensate pump for use with the unit

Remote Humidity Control Instructions (Adobe PDF)
Instructions for using the optional remote humidity controller (ducted applications).
