TrolMaster Hydro-X Thermostat Station
SKU:
tm12764
| Model:
TS-2
Regular price
$116.38
Unit price
Unavailable
TrolMaster Hydro-X Thermostat Station - 4 System is backordered and will ship as soon as it is back in stock.
What's In The Box?
What's In The Box?
- TrolMaster Hydro-X Thermostat Station TS-1 or TS-2
- 16-ft. RJ12 Cable
- 4-ft. RJ12 Cable
- RJ12 T-Splitter
- Owner's Manual
TrolMaster Hydro-X Thermostat Station
Sale priceFrom
$99.99
Regular price
$112.99
Unit price
Unavailable
TrolMaster Hydro-X Thermostat Station - 4 System is backordered and will ship as soon as it is back in stock.
The TrolMaster Hydro-X Thermostat Stations are designed to replace a thermostat connected to HVAC systems, both standard cooling or systems including heat pump and multi-stage systems.
Both stations allow Day/Night settings for up to 4 modules so that multiple systems can be controlled using the Hydro-X controller.
- TS-1: Wired to the standard HVAC cooling only system using the same low-voltage thermostat cable, it has the standard color-coded wiring as most thermostats.
- TS-2: Also, using low-voltage thermostat cable & color-coded wiring, it can control most HVAC systems including heat pump and multi-stage HVAC systems. The TS-2 thermostat station also has an adjustable delay time for each HVAC systems being activated. That minimizes high start-up (inrush current) and allows up to 4 systems to be safely controlled.
Additional Features
- LCD Display, Easy Operation
- Seamless Connection with Hydro-X
- Micro-SD for Firmware Upgrade
- Address Assignment
- Plug & Play Functionality
- ETL-Certified
-
Growing Product TypeDevice Station
-
System ControlsTemperature
-
Environment Temperature (degrees F)32-122
-
Maximum Operating Temperature (degrees F)122
-
Minimum Operating Temperature (degrees F)32
-
Maximum Amperage (Amps)0.10.5
-
Voltage (V)110-120, 220-240
-
Depth (in.)6.3
-
Depth (with front cover) (in.)6.3
-
Height (in.)3.39
-
Height (with front cover) (in.)3.39
-
Weight (lbs.)0.880.8
-
Width (in.)3.39
-
Width (with front cover) (in.)3.39
-
Additional FeaturesApplicable for Indoor Growing
