S&P PV-100X Powervent 4-in Inline Centrifugal Duct Fan

Name: S&P PV-100X Powervent 4-in Inline Centrifugal Duct Fan
Brand: S&P
Price: 214.0 USD
Availability: InStock

SKU: sp15694 | Model: PV-100X

$214.00

FREE shipping on orders over $45!

In Stock Usually ships in 5 business days.

Add extended protection plan. (Select one)

1-Year Replacement Extended Warranty - $24.99

learn more

A 1-year replacement warranty plan for commercial or residential use items under $250.

2-Year Replacement Extended Warranty - $29.99

learn more

A 2-year replacement warranty plan for commercial or residential use items under $250.

Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Request Callback | Email

Manufacturer's Warranty

5-Year Limited Warranty

What's In The Box?

S&P PV 100X Powervent 4-in. Inline Centrifugal Duct Fan
Pre-wired Junction Box
Mounting Bracket
Owner’s Manual

Info & Guides

Description

The S&P PV-100X Powervent 4-inch Inline Centrifugal Duct Fan is designed for use with standard 4-inch diameter round ducting. It provides 153 CFM of airflow and is ideal for helping to cool spaces passively or for use with a more complex ventilation and cooling system.

Durability: The galvanized steel casing with a baked enamel coating is designed to last.
Versatile: The PV-100X can be mounted at any angle and at any point along the duct.
Simple Installation: Pre-wired junction box and the extra-long inlet and discharge collars make installing this duct fan easy. A steel mounting bracket is included.

Powerful Operation

This S&P inline duct fan incorporates a powerful external rotor motor that has been factory-matched to a non-overloading backward curved centrifugal fan wheel. The motor is dynamically balanced to eliminate vibration and features safety thermal overload protection with automatic cut-out.

This completely enclosed permanent split capacitor start and run external rotor motor combination provides several benefits.

Airflow: Outstanding performance against the typically high static pressure in ducted ventilation systems.
Long Life: The Powervent inline duct fan has sealed-for-life bearings and will never require lubrication. It is designed for trouble-free continuous operation up to 40,000 hours.
Protection: A fully enclosed motor is protected from moisture, lint, and high-particulate air.
Full Speed Control: Control fan speed using voltage or frequency control regulators.

Additional Features

Fast Installation: A strong galvanized steel mounting bracket and pre-wired junction box are included for fast installation.
Working Temperature: The S&P inline duct fan can operate up to 158 degrees F in working airstreams.
Additional Insulation: The PV100X features Class F motor insulation
Standard Electrical: Inline duct fan operates on a 115 volt/60Hz single phase standard electrical connection.
Safety Listed: UL and cUL listed, ETL listed.
Airflow Tested: Bears the AMCA seal and is certified by the HVI (Home Ventilating Institute) for air performance.

Sylvane’s Expert Take

This S&P inline duct fan, with its permanently sealed rotor motor and backward curved centrifugal fan wheel, can deliver impressive airflow for cooling or ventilation in 4-inch ducting applications.

Outstanding Performance and Dependability: S&P’s durable motor design creates impressive airflow with maintenance-free convenience and dependable service.
Simple to Install and Maintain: Totally enclosed motor with permanent ball bearings never needs lubrication and is protected from external damage. The duct fan design, the pre-wired junction box, and the included mounting bracket make it easy to install.
