Mitsubishi HX Series 18,000 BTU Ductless Mini Split

SKU: mi16904k  |  Model: HX18NL
$2,789.00 $2,899.00

FREE shipping on orders over $45!

In Stock Ships within 1-2 business days.



Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Request Callback | Email

Manufacturer's Warranty

7-Year Limited Condenser Warranty, 5-Year Limited Parts Warranty

What's In The Box?

  • Mitsubishi 18,000 BTU HX Series Ductless Mini Split Air Handler MSZ-HX18NL
  • Mitsubishi 18,000 BTU HX Series Ductless Mini Split Condenser MUZ-HX18NL
  • Remote Control
  • Installation and Owner’s Manual

Description

The Mitsubishi HX Series 18,000 BTU ductless mini-split system offers year-round comfort for individual areas like bedrooms or offices. This wall-mounted unit uses cutting-edge inverter technology to deliver energy-efficient cooling during warmer months and dependable supplementary heating in colder periods.

With its sophisticated design, quiet performance, and remarkable energy efficiency, it serves as an excellent choice for creating an ideal and comfortable atmosphere.

Key Features and Benefits of the Mitsubishi HX Series 18,000 BTU Ductless Mini-Split

  • Efficient Cooling and Heating: This ductless mini-split heat pump offers 18,000 BTUs of cooling and 17,200 BTUs of heating capacity. Designed for simple temperature control, it effectively conditions spaces up to approximately 1,000 square feet, creating a comfortable indoor setting.
  • Advanced Inverter Technology: Featuring an inverter-driven compressor, this unit provides precise temperature control through adjustable capacity. This technology translates to significant energy conservation and reduced operational costs. It also carries an Energy Star certification and impressive efficiency ratings: SEER2 of 20 and HSPF2 of 9.5.
  • Dual Barrier Coating: Mitsubishi's patented Dual Barrier Coating technology is designed to prevent dust, fibers, smoke, and oil from accumulating inside the mini-split's heat pump. This helps the unit maintain optimal airflow and reduces the need for maintenance.
  • Enhanced Air Quality: This wall-mounted mini-split from Mitsubishi includes an Electrostatic Enzyme Filter. This feature helps create a healthier indoor atmosphere by trapping airborne contaminants, such as dust, allergens, and smoke.
  • R-454B Refrigerant: Utilizing the environmentally conscious R-454B refrigerant, this model achieves a lower global warming potential compared to other refrigerant choices.
  • Quiet and Comfortable Operation: With an exceptionally quiet noise level of just 30 decibels, this device operates almost silently. Its whisper-quiet performance makes it perfectly suited for tranquil settings such as bedrooms and offices.
  • Dry Mode: In warmer, wet conditions, the Smart Dry Mode provides superior humidity control, removing up to 3.4 pints of moisture per hour from the indoor air.
  • Robust and Reliable: The outdoor unit is equipped with a Blue Fin anti-corrosion coating engineered for resilience against severe weather, including conditions found in coastal and industrial areas. This feature helps protect your investment and prolong its service life.

Note: This model does not include a line set, which is required for installation. This model is compatible with a 1/4 X 1/2 Line Set

Flexible Control for Your Convenience

Experience ultimate convenience with the Mitsubishi HX Series 18,000 BTU Ductless Mini-Split's versatile control features. Adjust your comfort using the included handheld remote, the Comfort App, or optional wired and wireless thermostats. Effortlessly manage your ideal environment, whether you're home or away.

Sylvane’s Expert Take

The Mitsubishi 18,000 BTU Mini Split is a top-tier choice for dependable and efficient heating and cooling. Its inverter technology provides outstanding performance and significant energy savings, appealing to environmentally aware homeowners.

Its enhanced filtration and quiet operation make it ideal for individuals sensitive to air quality and noise. For a versatile and user-friendly mini split heat pump, the Mitsubishi HX Series delivers reliable performance.

Specifications

    Key Specifications

    • Energy Efficiency Ratio 2 (EER2)
      12.55
    • Mounting Type
      Wall
    • Number of Speeds
      4
    • Seasonal Energy Efficiency Ratio 2 (SEER2)
      20
    • Total Cooling Capacity (BTUs)
      17200
    • Total Heating Capacity (BTUs)
      18000

    General

    • Certifications
      ETL, AHRI
    • Color
      White
    • Compressor Type
      Inverter
    • Heat Mode
      Yes
    • Installation Type
      Professional Installation
    • Line Length Option
      No Line Set
    • Maximum Cubic Feet per Minute (CFM) (CFM)
      1816.0
    • Maximum Indoor Noise Level (dB)
      51
    • Maximum Operating Temperature - Cooling (degrees F)
      115
    • Maximum Operating Temperature - Heating (degrees F)
      75
    • Minimum Operating Temperature - Cooling (degrees F)
      14
    • Minimum Operating Temperature - Heating (degrees F)
      -5
    • Number of Zones
      1
    • Recommended Coverage Area (sq. ft.)
      1000
    • Refrigerant Type
      R-454B
    • Zone Cooling Capacity (BTUs)
      17200
    • Zone Heating Capacity (BTUs)
      18000

    Power

    • Maximum Cooling Amperage (Amps)
      10.1
    • Maximum Cooling Wattage (W)
      2330
    • Maximum Heating Amperage (Amps)
      11.4
    • Maximum Heating Wattage (W)
      2630
    • Voltage (V)
      208-230

    Dimensions

    • Indoor Unit Depth (in.)
      10.88
    • Indoor Unit Height (in.)
      12
    • Indoor Unit Weight (lbs.)
      28
    • Indoor Unit Width (in.)
      36.31
    • Maximum Line Length (ft.)
      65
    • Outdoor Unit Depth (in.)
      11.25
    • Outdoor Unit Height (in.)
      21.63
    • Outdoor Unit Weight (lbs.)
      90
    • Outdoor Unit Width (in.)
      31.5

    Additional Features

    • Additional Features
      Remote Control, Energy Star, Applicable for Indoor Growing, Pre-charged Refrigerant

    Warranty

    • Manufacturer's Warranty
      7-Year Limited Condenser Warranty, 5-Year Limited Parts Warranty
