Pioneer Flexible Insulated Line Set for Mini-Split Systems - 16ft.

Protect delicate copper piping from bending and kinking with Pioneer’s flexible line set for ductless mini-split systems. This line set is engineered with rigid steel, which is more adaptable for unique environments that require flexibility upon installation with a tighter bend radius. This product works with air conditioners and heat pumps such as liquid, suction, and hot gas discharge lines as long as the maximum recommended operating pressures are not exceeded per any indications on the equipment.

Available in four diameters:

• 1/4-inch - 3/8-inch
• 1/4-inch - 1/2-inch
• 1/4-inch - 5/8-inch
• 3/8-inch - 5/8-inch

Specifications

• Design Pressure: 650 PSIG
• Max Abnormal Pressure: 3600 PSIG
• Length: 16 feet
• Insulation Thickness: 1/2-inch
• Working Temperature: -40 degrees F to 248 degrees F
