Ruck Air Movement 16 inch EC 5238 CFM Axialine Tubeaxial Fan
Ruck Air Movement 16 inch EC 5238 CFM Axialine Tubeaxial Fan is backordered and will ship as soon as it is back in stock.
Deliver high-volume airflow wherever you need it with the Ruck Air Movement 16-inch Axialine EC 5238 CFM Tubeaxial Fan.
Built for contractors, facility managers, and OEM designers who require reliable, energy-efficient ventilation, this compact powerhouse moves up to 5,238 CFM while maintaining precise, stepless speed control. From manufacturing lines to large commercial HVAC systems, it supplies consistent air exchange with lower energy requirements than traditional motors.
Key Features and Benefits of the Ruck 16-Inch Axial EC Tubeaxial Fan
- High-Output Airflow: The 5,238 CFM airflow capacity rapidly removes heat, fumes, or stale air in large rooms and duct runs, keeping workspaces safer and more comfortable.
- Stepless EC Motor Control: Dial in exactly the speed you need, no wasted energy, making it perfect for variable-load processes or seasonal adjustments.
- Wide Temperature Range: Dependable performance in hot areas up to 140 degrees F, or cold areas down to -4 degrees F.
- Powder-Coated Construction: The fan housing resists corrosion and mechanical stress to offer a long service life in demanding industrial and commercial environments.
- IP55 Protection Rating: The IP55-rated housing shields the motor and electronics against dust and water, reducing downtime from environmental exposure.
Why EC Technology Changes the Game
This model’s integrated EC motor delivers stepless modulation from zero to full RPM. The benefits are dramatically lower kWh consumption and precise airflow matching that extends system life. For facilities aiming to hit energy-reduction targets or qualify for utility incentives, EC technology makes the upgrade decision straightforward.
Sylvane's Expert Take
Ruck’s 16-inch Axialine Fan hits the sweet spot between airflow and energy efficiency. Its CFD-driven blade design, IE3 motor, and VFD compatibility give facility managers the control they need, while the durable housing and IP ratings stand up to real-world conditions.
For anyone upgrading an existing duct run or designing a new industrial ventilation system, this fan offers reliable performance today with headroom for tomorrow’s efficiency standards.
-
Number of SpeedsVariable
-
TypeTubeaxial
-
ApplicationDucting, Industrial
-
CertificationsCE
-
ColorBlack, Yellow
-
ControlsElectronic
-
Maximum Air Temperature (degrees F)140
-
Maximum Cubic Feet per Minute (CFM) (CFM)5238.0
-
Amperage (Amps)10.3
-
Power SupplyHardwired
-
Voltage (V)208-230
-
Watts (W)1460
-
Depth (in.)14.5
-
Depth (with front cover) (in.)14.5
-
Duct Diameter (in.)15.7
-
Height (in.)18.9
-
Height (with front cover) (in.)18.9
-
Weight (lbs.)45
-
Width (in.)15.7
-
Width (with front cover) (in.)15.7
-
Additional FeaturesThermal Cutoff Protection
-
Manufacturer's Warranty3-Year Limited Warranty
