Built for use in the toughest of environments, the TPI 16-In. 3-Speed 1/8 HP Direct Drive Shutter Mounted Exhaust Fan is a commercial-grade ventilation solution. Featuring multiple fan speeds, it provides an airflow of up to 2,100 CFM for effective ventilation in industrial applications. There's no need for external framing or shutters since this unit installs from inside the wall.
Key Features Of The TPI CE16DS
- High-Capacity Performance: It's a 3-speed, 1/8 horsepower fan with a performance of up to 1,660 RPMs.
- Three Speeds: Choose from three fan speeds - Low (1,700 CFM), Medium (1,900 CFM), or High (2,100 CFM).
- Pull Chain: Use the pull chain to easily select from this fan's speed settings.
- Designed For Safety: Its durable 16-inch aluminum fan blades are protected by steel spiral wire guards.
- Enclosed Motor: Has a low-maintenance design thanks to its completely closed and permanently lubricated split capacitor motor
- Easy Installation: Can be installed from inside the wall, eliminating the need for external framing or shutters.
- Hardwired Design: This unit uses a 120-volt, single-phase electrical connection. A no-cord junction box is provided for direct wiring.
- Made In The USA: It's made in the U.S.A. with domestic and foreign components.
Overall Dimensions
- Height: 19.125 inches
- Width: 19.125 inches
- Depth: 7.18 inches
Summary
Keep your commercial building more comfortable and feeling better with this 16-inch shutter exhaust fan from TPI.
-
Number of Speeds3
-
TypeShutter Exhaust Fan
-
ApplicationResidential, Garage/Workshop, Basement, Crawlspace, Commercial/Industrial, Attic
-
ColorGray
-
ControlsToggle Switch
-
Housing MaterialSteel
-
Maximum Cubic Feet per Minute (CFM) (CFM)2100.0
-
Maximum RPM1660
-
California Residents⚠ WARNING: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer, and chromium, which is known to the State of California to cause birth defects and/or reproductive harm. For more information go to www.p65warnings.ca.gov.
-
Maximum Amperage (Amps)2.1
-
Power SupplyElectric
-
Voltage (V)110-120
-
Wiring StyleHardwired
-
Ceiling or Wall Cutout Length (in.)16.5
-
Ceiling or Wall Cutout Width (in.)16.5
-
Depth (in.)7.18
-
Height (in.)19.125
-
Shutter Fan Size (in.)16
-
Weight (lbs.)18
-
Width (in.)19.125
-
Manufacturer's Warranty1-Year Limited Warranty
