Amana 11,600 BTU J Series Ptac w/Electric Heat

SKU: am14334  |  Model: PTC123J35AXXX
$1,299.00

FREE shipping on orders over $45!

In Stock Usually ships in 6 business days.

Add extended protection plan. (Select one)

learn more

A 2-year commercial-grade repair warranty for products less than $1,500.

learn more

A 4-year commercial-grade repair warranty for products less than $1,500.

Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Request Callback | Email

Manufacturer's Warranty

1-Year Limited Unit Replacement Warranty, 5-Year Limited Parts Warranty

What's In The Box?

  • Amana 11,600 BTU J Series PTAC w/Electric Heat
  • Owner's Manual
  • Installation Instructions

Info & Guides

Description

Whether it's a hotel room, dorm, assisted living facility, or any other space up to 550 square feet, the Amana 11,900 BTU J Series PTAC with Electric Heat ensures year-round comfort. This adaptable unit effortlessly cools, heats, and dehumidifies, making it perfect for various settings.

Note: While this PTAC is equipped with Bluetooth and RF capabilities, a wall thermostat is required to operate the unit.

Bluetooth Control

You can easily manage your PTAC with just a touch of a button using the Amana Home app, available for download on iTunes and Google Play. This app simplifies the setup and configuration process and seamlessly integrates with Eden™ connectivity.

Year-Round Comfort Made Easy

The Amana J Series PTAC is a reliable option that offers a range of impressive features designed to keep you comfortable throughout the year.

  • Cooling Mode: With an impressive cooling performance of 11,900 BTUs, this unit can keep you cool and comfortable even during the hottest days of the year.
  • Heating Mode: When winter arrives, the electric heater delivers 11,000 BTUs of supplemental heat to keep you warm and cozy.
  • Moisture Removal: In cooling mode, the Amana J Series PTAC is highly effective at dehumidifying your space, removing up to 3.6 pints of moisture per hour.
  • Fan Operation: During both cooling and heating modes, you can choose from three different fan speeds: low, high, or auto. You can also run the fan alone to circulate air and improve ventilation.

Required Wall Sleeve

The wall sleeve required for installation isn’t included with the unit and must be purchased separately.

Additional Features

  • Enhanced Energy Efficiency: Enjoy efficient cooling and heating performance with an 11.4 Energy Efficiency Ratio (EER).
  • Whisper-Quiet Operation: Rest easy with a 2-speed motor and ultra-silent indoor fan that provide a disturbance-free and peaceful environment.
  • Automatic Freeze Prevention: If temperatures drop below 40 degrees Fahrenheit, the fan motor and heater will automatically switch on to prevent freezing.
  • Optimal Airflow: Experience maximum comfort with up to 330 cubic feet per minute (CFM) of airflow.
  • Air Filter: Breathe easy with the conveniently located and accessible air filter that keeps your room's air clean and free of allergens.

  • R-32 Refrigerant: R32 is up to 12% more efficient than R410A. New California regulations require a Global Warming Potential (GWP) of 750 or less. R32 has a GWP of 677

Summary

The Amana PTAC is a versatile year-round comfort solution capable of cooling, heating, and much more.

Specifications

    Key Specifications

    • Energy Efficiency Ratio (EER)
      11.5
    • Number of Speeds
      2

    General

    • California Residents
      ⚠ WARNING: Cancer and Reproductive Harm www.p65warnings.ca.gov.
    • Certifications
      ETL
    • Color
      White
    • Controls
      Electronic
    • Electric Heat BTU's (BTUs)
      12000
    • Heater Type
      Electric Coil
    • Heating BTUs (BTUs)
      11900
    • Maximum Cubic Feet per Minute (CFM) (CFM)
      330.0
    • Maximum Operating Temperature (degrees F)
      115
    • Minimum Operating Temperature (degrees F)
      40
    • Moisture Removal per Hour (pints)
      3.6
    • Recommended Coverage Area (sq. ft.)
      550
    • Refrigerant Type
      R-32

    Power

    • Branch Circuit Fuse (amps)
      20
    • Electric Heat Max Amps (Amps)
      15.5
    • Electric Heat Max Wattage (W)
      3570
    • Maximum Cooling Amperage (Amps)
      5.6
    • Maximum Cooling Wattage (W)
      1135
    • Maximum Heating Amperage (Amps)
      15.5
    • Maximum Heating Wattage (W)
      3570
    • Plug Face Type
      6-20P
    • Power Cord Length (ft.)
      4.83
    • Voltage (V)
      208-230

    Dimensions

    • Cut Out Dimensions (H x W) (in.)
      16.25 x 42.25
    • Depth (in.)
      21.5
    • Depth (with front cover) (in.)
      21.5
    • Height (in.)
      16.1
    • Height (with front cover) (in.)
      16.1
    • Weight (lbs.)
      108
    • Width (in.)
      42.0
    • Width (with front cover) (in.)
      42.0

    Additional Features

    • Additional Features
      Programmable Thermostat, Fan-Only Mode

    Warranty

    • Manufacturer's Warranty
      1-Year Limited Unit Replacement Warranty, 5-Year Limited Parts Warranty
