Broan High Capacity Wall Heater
Broan High Capacity Wall Heater - 2000/4000W is backordered and will ship as soon as it is back in stock.
Have a question or need a quote? Ask Our Experts
Manufacturer's Warranty
Manufacturer's Warranty
What's In The Box?
What's In The Box?
- Broan High-Capacity Fan-Forced Wall Heater (2000W, 3000W, or 4000W)
- Housing Mask Included
- Installation Guide/Owner's Manual
Info & Guides
Info & Guides
Broan High Capacity Wall Heater
Description
Description
For versatility and dependable supplemental heat, the Broan High-Capacity Wall Heaters can fill the bill. Wire for 240- or 208-volt wiring, select from 2000, 3000, or 4000 watts of heating power to suit the size space you need to heat.
Built-in thermostats and variable heat settings make these UL-listed heaters versatile in use, and their sturdy construction gives them durability. They can also be field-converted to half-wattage power.
Supplemental Heat with Options
These high-capacity heaters feature a steel-sheathed, plate-finned, heavy-duty enclosed heating element that produces heat quickly and quietly. In addition, the adjustable thermostat is a built-in disc-type with a security cover.
- 2000 Watt: 200 sq. ft. coverage with 6,827 BTUs at 240 Volts / 8.33 Amps
135 sq. ft. coverage with 5,120 BTUs at 208 Volts / 7.21 Amps
- 3000 Watt: 300 sq. ft. coverage with 10,204 BTUs at 240 Volts / 12.5 Amps
200 sq. ft. coverage with 7,680 BTUs at 208 Volts / 10.82 Amps
- 4000 Watt: 400 sq. ft. coverage with 13,653 BTUs at 240 Volts / 16.67 Amps
265 sq. ft. coverage with 10,204 BTUs at 208 Volts / 14.42 Amps
Power can be tapped from a nearby circuit, depending on the wattage selected and the amp rating of the circuit. For low-amp circuits, the heater can be easily converted to half-wattage to avoid over-loading.
Existing or New Construction
Easily installed in between wall studs, you can add a Broan fan-forced wall heater to an existing room or build into new construction. Heavy-duty 22-gauge steel construction housing mounts directly to studs.
It should be located 12 inches from floor or adjacent walls and is designed for 24-inch on center stud construction, framing in between if necessary. A housing mask is included for use during new construction and should be removed before operating.
Built-In Thermostat
Equipped with an on-board thermostat and simple dial control for infinite variable heat settings. You can use it to add heat on cold mornings or evenings as needed, or use it all day during the winter for extra warmth.
Front-mounted design is easy to access and use. The grille is finished with white, baked enamel for durability, blending seamlessly into any décor.
Additional Features
- Fan-forced Heat: Electric heating element and blower fan distribute warmth throughout the space.
- Downward Louvers: Even fan-forced heat is distributed evenly through the area.
- Grille Dimensions: 16.375 W x 20.25 H inches
- Overload Protection: Manual reset thermal overload protector shuts down the heater in event of overheating.
- Permanently Lubricated Motor: Designed with a lubricated motor, you can enjoy years of trouble-free operation. The 4000-watt model is a completely sealed, lubricated motor.
- Baked Enamel Finish: Built to last from 18-gauge steel with white finish.
Summary
The Broan High-Capacity Wall Heaters feature heavy-duty construction and versatile installation options for 240-volt & 208-volt power supply. Fan-forced heat, white baked enamel finish, and UL-listed. Select from three wattage options.
Specifications
Specifications
-
Heater TechnologyFan-forced
-
Number of Heat SettingsVariable
-
TypeWall
-
California Residents⚠ WARNING: Cancer and Reproductive Harm www.p65warnings.ca.gov.
-
CertificationsUL
-
ColorWhite
-
ControlsManual
-
Heating BTUs (BTUs)10204, 136537680, 102045120, 6827
-
Maximum Amperage (Amps)16.6712.58.33
-
Maximum Wattage (W)400030002000
-
Power SupplyHardwired
-
Voltage (V)208-230
-
Depth (in.)3.75
-
Depth (with front cover) (in.)3.75
-
Height (in.)20.2920.2520.25
-
Height (with front cover) (in.)20.2920.2520.25
-
Weight (lbs.)23
-
Width (in.)16.37
-
Width (with front cover) (in.)16.37
-
Additional FeaturesWall-Mountable, Automatic Overheat Protection, Bathroom-Friendly, Has Thermostat
-
Manufacturer's Warranty1-Year Warranty
