Canarm 20-in. Shutter Mounted Exhaust Fan

Name: Canarm 20-in. Shutter Mounted Exhaust Fan
Brand: Canarm
Price: 518.0 USD
Availability: InStock

SKU: ca10140 | Model: S20-F2

$518.00

FREE shipping on orders over $45!

In Stock Usually ships in 5 business days.

Number of Speeds

Product variants

Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Request Callback | Email

Manufacturer's Warranty

1-Year Limited Warranty

What's In The Box?

Canarm 20-inch Shutter Mounted Exhaust Fan
Owner's Manual

Info & Guides

Description

Canarm 20-inch Shutter Mounted Exhaust Fans are designed and built to last, featuring a completely enclosed motor mounted on a heavy-gauge steel rod mount, plus a rugged steel welded box housing.

Speed Options

Select either a single speed or 2-speed model based on your operating needs. This exhaust fan is hard-wired at 120-volts, and full instructions are included to make installation fast and easy.

Single Speed Fan: Requires a simple toggle switch.
Two Speed Fan: Requires a 2-speed control or a 3-position toggle switch.

Safe & Reliable

The Canarm 20-inch exhaust fan motor is thermally protected and ETL certified to ensure safe operation. The aluminum louvers are supported by long-life nylon bushings and all fans are shipped completely assembled and ready to install.

Specification Highlights

Durable steel construction has a gray powder coat finish that resists rust and corrosion.
OSHA certified with a heavy wire chrome-plated guard.
Framing Dimensions: 23-in. x 23-in.
ETL Certified

Specifications

Key Specifications

Number of Speeds

2: 2

1: 1
Sound Level (Sones) (sones)

4.0
Type

Shutter Exhaust Fan

General

Application

Commercial/Industrial
California Residents

⚠ WARNING: This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. See: www.P65Warnings.ca.gov
Certifications

ETL
Color

Gray
Controls

Manual
Housing Material

Powder-Coated Steel
Maximum Cubic Feet per Minute (CFM) (CFM)

2: 3440.0

1: 3420.0
Maximum RPM

2: 1725

1: 1625

Power

Amperage (Amps)

2: 5.5

1: 4.1
Power Supply

Hardwired
Voltage (V)

110-120
Watts (W)

206

Dimensions

Ceiling or Wall Cutout Length (in.)

22.75
Ceiling or Wall Cutout Width (in.)

22.75
Depth (in.)

6.75
Depth (with front cover) (in.)

6.75
Height (in.)

25.25
Height (with front cover) (in.)

25.25
Shutter Fan Size (in.)

2: 24

1: 20
Weight (lbs.)

2: 45

1: 41
Width (in.)

25.25
Width (with front cover) (in.)

25.25
