MRCOOL DIY Easy Pro 18,000 BTU Ductless Mini Split Heat Pump

Name: MRCOOL DIY Easy Pro 18,000 BTU Ductless Mini Split Heat Pump
Brand: MRCOOL
Price: 1806.0 USD
Availability: InStock

SKU: mr19002k | Model: EZPRO-18-HP-23011DE-O

$1,806.00 $1,949.99

Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Email

Manufacturer's Warranty

3-Year Parts Limited Warranty; 5-Year Compressor Limited Warranty

What's In The Box?

MRCOOL DIY Easy Pro 18,000 BTU Indoor Air Handler EZPRO-18-HP-WMAH-230DE-O
MRCOOL DIY Easy Pro 18,000 BTU Outdoor Compressor EZPRO-18-HP-C-23011DE-O
11.5 Foot 1/4 x 1/2-inch Lineset
Remote Control
Smart Wi-Fi Adaptor
Owner's Manual, Guides, and Other Documents

Info & Guides

The MRCOOL DIY EZ PRO 18,000 BTU Ductless Mini-Split Heat Pump delivers year-round heating and cooling without the cost of professional installation. This single-zone wall-mount mini-split installs quickly using the included pre-charged Quick Connect line set, giving you full climate control with a true DIY setup.

Built for bedrooms, garages, home offices, and rental properties where running ductwork is impractical, the Easy Pro gives you full control through built-in Wi-Fi and an included remote control. This single-zone system handles one space independently, making it a practical choice for supplemental conditioning or for rooms your central system can't reach.

Key Features and Benefits of the MRCOOL DIY EZ PRO 18,000 BTU Ductless Mini-Split Heat Pump

Heating and Cooling: 17,000 BTU cooling and 18,000 BTU heating capacity cover spaces up to 800 square feet, giving you year-round comfort from a single wall-mount system.
Energy Efficiency: Rated at 20.0 SEER2, 9.8 EER2, 8.5 HSPF2, and 6.6 HSPF2, so you spend less on energy across both cooling and heating seasons.
Inverter Rotary Compressor: A variable-speed inverter rotary compressor adjusts output to match real-time demand, reducing energy waste compared to fixed-speed systems.
Quick Connect Technology: Tool-free Quick Connect fittings create a secure, leak-proof seal without vacuum pumps, manifold gauges, or specialized HVAC equipment.
R-454B Refrigerant: Factory-charged with R-454B future-ready refrigerant, keeping your system aligned with current and upcoming industry standards.
Wide Operating Range: Operates in ambient temperatures from -13 degrees F in heating mode to 122 degrees F in cooling mode, keeping you comfortable through seasonal extremes.
MRCOOL Comfort App: Built-in Wi-Fi connectivity connects the mini-split to your home network, giving you remote access to adjust temperature, switch modes, create schedules, and monitor system performance directly from your smartphone from anywhere.
Quiet Operation: Indoor noise measures as low as 18.5 dB on silent to 46.5 dB on turbo, with outdoor levels at 55 dB, keeping disruption minimal.
AHRI and cETLus: AHRI and cETLus certified, confirming independently verified performance ratings and electrical safety compliance for your installation.

Planning Your Line Set and Installation

The DIY EZ PRO 18,000 BTU Ductless Mini-Split features an 11.5-foot pre-charged Quick Connect line set that works well when the indoor air handler and outdoor condenser are installed close together. If your layout requires more distance, upgrade with a 1/4 x 1/2-inch Quick Connect line set that comes in 16-, 25-, 35, and 50-foot lengths.

This mini-split requires a 208-230V, single-phase, 60 Hz power supply with a dedicated 20-amp breaker for the outdoor condenser. The indoor air handler measures 38.23 x 8.98 x 12.64 inches and weighs 30.64 pounds, while the outdoor condenser measures 30.12 x 11.93 x 21.85 inches and weighs 62.61 pounds.

Sylvane's Expert Take

If you're a homeowner looking to add dedicated heating and cooling to a single room without tearing into walls for ductwork, the MRCOOL Easy Pro 18K is designed for exactly that. Unlike professionally installed mini-split systems that require a licensed HVAC technician and can add thousands of dollars in labor costs, this system lets you handle the entire setup yourself, thanks to pre-charged Quick Connect line sets that eliminate vacuum pumps, manual refrigerant charging, and specialized tools. The included 11.5-foot pre-charged line set means you can go from unboxing to conditioned air in nearly a single afternoon without scheduling a service appointment or waiting on a contractor.

Key Specifications

Energy Efficiency Ratio 2 (EER2)

9.8
Mounting Type

Wall
Number of Speeds

Variable
Seasonal Energy Efficiency Ratio 2 (SEER2)

20.0
Total Cooling Capacity (BTUs)

17000
Total Heating Capacity (BTUs)

18000

General

Certifications

AHRI, cETLus
Color

White
Compressor Type

Inverter Rotary
Heat Mode

Yes
Installation Type

Do-It-Yourself (DIY)
Line Length Option

11.5 ft
Maximum Indoor Noise Level (dB)

46.5
Maximum Operating Temperature - Cooling (degrees F)

122.0
Maximum Operating Temperature - Heating (degrees F)

75.0
Minimum Operating Temperature - Cooling (degrees F)

5
Minimum Operating Temperature - Heating (degrees F)

-13.0
Number of Zones

1
Recommended Coverage Area (sq. ft.)

800
Refrigerant Type

R-454B
Zone Cooling Capacity (BTUs)

17000
Zone Heating Capacity (BTUs)

18000
