Pioneer 36,000 BTU Diamante Pro High-Wall Series Ductless Mini Split

Name: Pioneer 36,000 BTU Diamante Pro High-Wall Series Ductless Mini Split
Brand: Pioneer
Price: 2168.0 USD
Availability: InStock

SKU: pi17062k | Model: WYT036GLSI20RL

$2,168.00

Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Request Callback | Email

Manufacturer's Warranty

5-Year Limited Warranty

What's In The Box?

Pioneer 36,000 BTU Diamante Pro High-Wall Outdoor Unit YN036GLSI20RPF
Pioneer 36,000 BTU Diamante Pro High-Wall Indoor Unit WT036GLSI20HLF
16-Foot Line Set
Remote Control
Remote Control Holder
Indoor Unit Mounting Plate
Wall Sleeve
Hardware
Owner’s Manual

Info & Guides

Description

Designed for midsize homes and light commercial spaces, the Pioneer 36,000 BTU Diamante Pro High-Wall Series Ductless Mini Split delivers reliable year-round climate control through inverter-driven heat-pump technology. It provides efficient cooling and heating without the complexity of ductwork, helping you maintain consistent comfort while reducing energy waste.

This single-zone system is sized for areas up to 1,400 square feet, making it a practical choice for open living areas, offices, and retrofit projects. The compact indoor air handler mounts high on the wall, giving installers flexible placement options and preserving interior aesthetics.

Key Features and Benefits of Pioneer 36,000 BTU Diamante Pro

Inverter Compressor Efficiency: The variable-speed compressor automatically adjusts output from 7,500 to 36,000 BTU per hour, trimming energy use during part-load conditions and keeping temperature swings to a minimum.
Seasonal Efficiency: A 19 SEER2 cooling efficiency and 9.0 HSPF2 heating efficiency rating help lower operating costs compared with fixed-speed systems of similar capacity.
Four Operating Modes: Cooling, Heating, Dry, and Ventilation Modes let you manage humidity, circulate fresh air, or reach setpoints in every season with a single piece of equipment.
Wide Temperature Range: Engineered to perform from -4 degrees F to 122 degrees F, so you can rely on consistent comfort during extreme heat or cold snaps.
Dual-Axis Airflow: The motorized horizontal and vertical louvers distribute conditioned air evenly, eliminating hot and cold spots across large rooms.
Quiet Indoor Operation: Sound levels as low as 28 dB create a near-silent background, making the system suitable for bedrooms, conference rooms, and classrooms.
ECO and SLEEP Modes: Automatic setback programming reduces energy draw during unoccupied hours or overnight, helping you manage utility costs without manual adjustments.
TURBO Mode: Activates maximum fan speed and compressor output to bring the space to temperature quickly after start-up or door openings.
Low-Maintenance Design: Self-cleaning coils and washable, reusable filters cut down on routine service tasks and keep airflow consistent.
Line Set Included: A 16-foot 1/4 x 5/8 line set is included.

Note: This mini-split air conditioner must be installed by a qualified professional.

Installer Friendly

Pioneer ships this system ready for field installation with pre-flared copper lines, quick-connect wiring terminals, and clearly labeled service ports. The outdoor condenser uses R-454B, a lower-GWP refrigerant that aligns with evolving environmental regulations and may simplify future compliance requirements.

Sylvane’s Expert Take

Pioneer’s Diamante Pro delivers commercial-grade performance in a straightforward package. The inverter compressor, broad temperature range, and included installation kit make it a dependable solution for spaces where ductwork is impractical or energy efficiency is a priority. Quiet indoor operation and programmable modes add day-to-day value for occupants, while R-454B refrigerant supports long-term sustainability goals. When you need robust capacity without complexity, this mini split checks the essential boxes with room to spare.

Specifications

Key Specifications

Energy Efficiency Ratio 2 (EER2)

9
Mounting Type

Wall
Number of Speeds

Variable
Seasonal Energy Efficiency Ratio 2 (SEER2)

19
Total Cooling Capacity (BTUs)

36000
Total Heating Capacity (BTUs)

36000

General

California Residents

⚠ WARNING: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer and reproductive harm. For more information go to www.p65warnings.ca.gov.
Certifications

AHRI, cETLus
Color

White
Compressor Type

Inverter
Heat Mode

Yes
Installation Type

Professional Installation
Line Length Option

16 ft
Maximum Cubic Feet per Minute (CFM) (CFM)

847.0
Maximum Indoor Noise Level (dB)

63
Maximum Operating Temperature - Cooling (degrees F)

122
Maximum Operating Temperature - Heating (degrees F)

86
Minimum Operating Temperature - Cooling (degrees F)

5
Minimum Operating Temperature - Heating (degrees F)

-4
Number of Zones

1
Recommended Coverage Area (sq. ft.)

1400
Refrigerant Type

R-454B
Zone Cooling Capacity (BTUs)

36000
Zone Heating Capacity (BTUs)

36000
