S&P TRLPe110 Low Profile 130 CFM Energy Recovery Ventilator

SKU: sp15643 | Model: TRLPe110

$1,496⁰⁰

Option

Plug Hardwired

Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Email

Manufacturer's Warranty

10-Year Core Warranty, 5-Year Unit Warranty

What's In The Box?

S&P TRLPe110 30-130 CFM Energy Recovery Ventilator
6-inch Duct Collars (4)
MERV 8 Filter (2) - 7 1/2 x 10 1/2 x 1 inches
Installation Manual

Info & Guides

Description

Tight joist bays and shallow wall cavities rule out a lot of ventilation equipment. The S&P TRLPe Low Profile 130 CFM Energy Recovery Ventilator fits spaces as shallow as 9.5 inches. It swaps stale indoor air for filtered outdoor air at 30 to 130 CFM in homes and light commercial spaces. You can choose a plug-in or hardwired power configuration to match your electrical setup.

The crossflow core uses S&P air-to-air technology to keep the incoming and outgoing airflows separate. It recovers 82 percent of energy at 34 CFM and 62 percent at 138 CFM, so you get the best return at lower speeds. At 110 CFM and 0.5 inches w.g. of static pressure, you still get up to 68 percent recovery (60 percent in winter and 44 percent in summer temperatures).

Key Features and Benefits of the S&P TRLPe Low Profile 130 CFM Energy Recovery Ventilator

Dual EC Motors: The ventilator uses 2 115-volt electronically commutated impellers that draw less energy than traditional AC motors, with a 53-watt rating and 0.85-amp maximum draw for low-cost continuous ventilation.
Low-Profile Housing: The ventilator measures 30.75 x 22.25 x 9.5-Inches (L x W x H) and weighs 35 pounds, so you can mount it in a ceiling or a wall.
Duct Flexibility: Side ports fit 6-inch round or oval ducts, and you can balance each airstream on its own to make up for unequal duct run lengths.
Included Mounting Hardware: A wall-mount bracket, a ceiling hanging system, and 4 plastic 6-inch duct collars come with the ventilator, so you can start installing right away.
MERV 8 Filtration: MERV 8 filters clean both the outdoor and return airstreams, so the fresh air you bring in is filtered before it reaches your rooms.
Frost-Resistant Core: The engineered resin core transfers moisture to prevent moisture and frost buildup, so you need no condensate pan or drain.
Digital Controls: An onboard electronic digital controller sets variable fan speeds, and a speed-adjustable high-speed boost mode gives you extra airflow when the house needs it.
Certified Performance: The ventilator is HVI certified, cETLus and cULus listed, and CSA certified, so its airflow performance and electrical safety have been independently tested.

Plug-In vs Hardwired: Choose Your Power Configuration

The TRLPe comes in plug-in and hardwired power configurations, so you can match the ventilator to the electrical service where you install it.

Plug-In Model TRLPe110: The TRLPe110 uses a plug-in power supply that connects to a standard outlet near the mounting location, which suits retrofits where an outlet is already within reach.
Hardwired Model TRLPe110H: It connects directly to your electrical circuit, which gives you a permanent connection with no exposed cord when your installation requirements call for one.

Sylvane's Expert Take

If you're adding balanced ventilation to a home with shallow ceilings or tight wall cavities, start with the TRLPe. Set it to run continuously near the low end of its airflow range, where energy recovery is highest and the EC motors use the least power. Both power configurations perform the same, so your only decision is whether the mounting spot has an outlet nearby or needs a permanent connection. Either way, you get fresh air without losing most of the energy you paid to heat or cool it.
