TPI CE14DS 14-In. 3-Speed 1/8 HP Direct Drive Shutter Mounted Exhaust Fan

Name: TPI CE14DS 14-In. 3-Speed 1/8 HP Direct Drive Shutter Mounted Exhaust Fan
Brand: TPI
Price: 420.0 USD
Availability: InStock

SKU: tp13499 | Model: CE 14-DS

$420.00

FREE shipping on orders over $45!

In Stock Usually ships in 10 business days.

Add extended protection plan. (Select one)

1-Year Replacement Extended Warranty - $39.99

learn more

A 1-year replacement warranty plan for commercial or residential use items under $500.

2-Year Replacement Extended Warranty - $49.99

learn more

A 2-year replacement warranty plan for commercial or residential use items under $500.

Have a question or need a quote? Ask Our Experts

Live Chat | 1 (800) 934-9194 | Request Callback | Email

Manufacturer's Warranty

1-Year Limited Warranty

What's In The Box?

TPI CE14DS 14-In. 3-Speed 1/8 HP Direct Drive Shutter Mounted Exhaust Fan
Owner's Manual
No-Cord Junction Box

Description

Easy to install and operate, the TPI 14-In. 3-Speed 1/8 HP Direct Drive Shutter Mounted Exhaust Fan is the perfect ventilation solution for heavy-duty applications. Effective in commercial and industrial settings, this unit installs from the inside wall, eliminating the need for shutters and framing. A powerful fan, it provides a maximum airflow of 1,520 CFM.

Top Features Of The TPI CE14DS

Powerful Performance: This multi-speed, 1/8 horsepower fan provides up to 1,660 RPMs.
Multiple Fan Levels: Select from three fan speeds - Low (1,250 CFM), Medium (1,400 CFM), or High (1,520 CFM).
Easy Operation: Use the pull chain to easily switch between speed settings.
Fan Blade Protection: Its 14-inch aluminum fan blades are protected by steel spiral wire guards.
Low-Maintenance: The split capacitor motor is completely enclosed and features a permanently lubricated sleeve bearing to ensure low-maintenance use and to prevent overheating.
Simple to Install: It installs from inside the wall without the need for external framing or shutters.
Hardwired: This fan requires a 120V, 1 phase electrical connection, and it must be hardwired. A no-cord junction box is provided for direct wiring.
American-Made: It's made in the U.S.A. with domestic and foreign components.

Overall Dimensions

Height: 17.125 inches
Width: 17.125 inches
Depth: 7.18 inches

Summary

Improve indoor air quality and provide effective ventilation to toughest of environments with this 14-inch TPI Shutter Exhaust Fan.

Specifications

Key Specifications

Number of Speeds

3
Type

Shutter Exhaust Fan

General

Application

Residential, Garage/Workshop, Basement, Crawlspace, Commercial/Industrial, Attic
California Residents

⚠ WARNING: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer, and chromium, which is known to the state of California to cause birth defects and/or reproductive harm. For more information go to www.P65Warnings.ca.gov.www.p65warnings.ca.gov.
Color

Gray
Controls

Toggle Switch
Housing Material

Steel
Maximum Cubic Feet per Minute (CFM) (CFM)

1520.0
Maximum RPM

1660

Power

Amperage (Amps)

2
Power Supply

Hardwired
Voltage (V)

110-120

Dimensions

Ceiling or Wall Cutout Length (in.)

14.5
Ceiling or Wall Cutout Width (in.)

14.5
Depth (in.)

7.18
Depth (with front cover) (in.)

7.18
Height (in.)

17.125
Height (with front cover) (in.)

17.125
Shutter Fan Size (in.)

14
Weight (lbs.)

17
Width (in.)

17.125
Width (with front cover) (in.)

17.125

Warranty

Manufacturer's Warranty

1-Year Limited Warranty
