Broan FIN-6MD FRESH-IN Motorized Supply Damper
Broan FIN-6MD FRESH-IN Motorized Supply Damper is backordered and will ship as soon as it is back in stock.
Have a question or need a quote? Ask Our Experts
Manufacturer's Warranty
Manufacturer's Warranty
What's In The Box?
What's In The Box?
- Broan FIN-6MD FRESH-IN Motorized Supply Damper
- Owner's Manual
Info & Guides
Info & Guides
Broan FIN-6MD FRESH-IN Motorized Supply Damper
Description
Description
Control the fresh air entering your home or building's air handling unit with the Broan FRESH-IN Motorized Supply Damper. Featuring integrated humidity and temperature monitoring, the Broan FIN-6MD uses the last 48 hours of data to estimate the best time of the day to allow fresh air in.
Proper installation in a conventional inline configuration or direct mounting to the air handling unit ensures compliance with ASHRAE 62.2 requirements.
Continuous Monitoring
With its built-in humidity and temperature monitoring, the Broan Motorized Supply Damper learns your building's air handler's operation patterns and climate variations to determine the best time to let fresh air into the unit.
Installation Made Easy
Engineered with the end user in mind, this motorized damper from Broan offers the ultimate in installation flexibility.
- Inline Installation: Capable of being installed in the conventional inline configuration, it can be placed on a horizontal surface or suspended beside, below, or above studs and trusses.
- Direct Mounting: This unit can be mounted directly onto your air handling unit.
- Simple Wiring: A removable terminal block for easier wiring installation.
Additional Features
- Long Warranty: The Broan FRESH-IN is protected by a 5-year limited warranty.
- Operating Modes: Features five selectable comfort modes to best suit your specific climate zone.
- Air Leakage Protection: An insulated duct and port seal protects against air leakage and condensation.
- Controls: An integrated ON/OFF switch turns the damper off at any time without changing settings and can also be connected to a remote switch. A cover guards against unintentional control changes.
- Integrated Switch: Allows the damper to be turned off without a change of settings.
- ASHRAE Standard: When properly installed and set, this unit ensures compliance with ASHRAE 62.2.
- UL Listed: The damper conforms to UL1995.
Summary
The smart Broan FRESH-IN motorized supply damper makes it easy to achieve ASHRAE code compliance, and control the fresh air entering your home's air handling unit.
Specifications
Specifications
-
TypeDamper
-
CertificationsUL, ETL, ASHRAE 62.2-2016
-
ColorGray
-
ControlsElectronic
-
Housing MaterialGalvanized Steel
-
Type of FanAir Supply Fan
-
Power SupplyHardwired
-
Voltage (V)24
-
Depth (in.)6.375
-
Depth (with front cover) (in.)6.375
-
Duct Diameter (in.)6.0
-
Height (in.)7.75
-
Height (with front cover) (in.)7.75
-
Weight (lbs.)2.5
-
Width (in.)10.625
-
Width (with front cover) (in.)10.625
-
Additional FeaturesHumidity Sensor
-
Manufacturer's Warranty5-Year Limited Warranty
