Hessaire 16 Inch CFM Shutter Mounted Exhaust Fan
Description
Description
Exhaust your attic, detached garage, mini greenhouse, or workshop up to 350 square feet with the Hessaire 16 Inch Exhaust Fan. Designed to retrofit any existing shutter exhaust fan, select between either a three- or variable speed fan with 1,400 cubic feet per minute of airflow (CFM). Highly-efficient and durable, these fans are made in the USA.
Fan Speed Options
Select between either a three- or variable fan speed option with 1,400 cubic feet per minute of airflow in areas up to 350 square feet.
**The variable speed fan requires an additional purchase of an eight-amp variable speed controller for the 16-inch vent fan and must be installed by a professional electrician.
Durable Construction
Industrial-grade, reinforced aluminum construction, these fans come pre-assembled and ready to use out of the box. This 16-inch shutter fan replaces any standard exhaust shutter fan for home garages, greenhouses, and workshops up to 350 square feet.
- Quiet Operation: At just 6.4 sones, this fan is no louder than a standard conversation.
- Automatic Shutters: The self-closing aluminum shutters are fitted with weather-stripping to provide a tight seal against external noise and close quietly.
- Permanently Sealed Motor: A permanently sealed ball-bearing motor never needs lubrication.
- Corrosion-Resistant: Gray powder coating protects against weathering and rust.
- IP55 Rating: The totally enclosed motor is resistant to dust and light water splashes.
Additional Features
- OSHA Compliant: With 1/2-inch openings, this fan adheres to OSHA compliancy.
- Power Cord: Pre-wired and ready to use, these fans feature a nine-foot plug and play power cord.
- UL-Certification: Designed and rated for safety, this fan carries a UL705 certification.
- Thermally Protected: In case the fan motor locks up, the thermal protection will cut power to the fan to prevent overheating.
Summary
Remove toxic fumes and gases from any space up to 350 square feet with the Hessaire 16 Inch Exhaust Fan.
What Customers Love
- Quality Construction: Made in the USA, these top-quality fans provide years of use.
Things to Consider
- Variable Speed Switch: In order to use the variable speed fan, an eight-amp controller switch is required, and is not included with the fan. Without the variable switch, the variable speed fan will run continuously on high when in use.
- Professional Installation: The variable controller switch should be professionally installed by a certified electrician.
Specifications
Specifications
-
Number of SpeedsVariable3
-
Sound Level (Sones) (sones)6.4
-
TypeShutter Exhaust Fan
-
ApplicationBasement, Garage/Workshop, Crawlspace, Residential, Commercial/Industrial, Attic
-
California Residents⚠ WARNING: This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. See: www.P65Warnings.ca.gov
-
CertificationsUL
-
ColorGray
-
ControlsManual
-
Housing MaterialGalvanized Steel
-
Maximum Cubic Feet per Minute (CFM) (CFM)1400.0
-
Maximum RPM1550
-
Recommended Coverage Area (sq. ft.)350
-
Amperage (Amps)1
-
Power SupplyPlug
-
Voltage (V)110-120
-
Watts (W)115
-
Ceiling or Wall Cutout Length (in.)16.5
-
Ceiling or Wall Cutout Width (in.)16.5
-
Depth (in.)12.0
-
Depth (with front cover) (in.)12.0
-
Height (in.)16.0
-
Height (with front cover) (in.)16.0
-
Shutter Fan Size (in.)16
-
Weight (lbs.)17
-
Width (in.)19.0
-
Width (with front cover) (in.)19.0
-
Additional FeaturesThermal Cutoff Protection, Applicable for Indoor Growing
-
Manufacturer's Warranty1-Year Limited Warranty
